Maco Trend Tilt & Turn Full System (Concealed Fix)

Maco Trend Tilt & Turn Full System (Concealed Fix) - OBSOLETE

This item is now OBSOLETE, please follow the link for a suitable replacement:

For 9mm axis systems we suggest the Roto NT 'R' Royal Full Tilt & Turn System (Concealed Fix) – 9mm Eurogroove

https://store.northwesthardware.co.uk/windows/tilt-and-turn-hardware/Roto-NT-R-Royal-Concealed-Fix.html

For 13mm axis systems we suggest the Roto Designo II Full Tilt & Turn System (Concealed Fix) – 13mm Eurogroove*

https://store.northwesthardware.co.uk/Roto-Designo-II-Full-Tilt-Turn-System-13mm-Concealed-Fix-PVC-Aluminium.html

Maco Full Tilt & Turn system, concealed fixed, for PVC, Aluminium and Timber windows with 9mm or 13mm Eurogroove Axis.

Technical Details:
Max sash weight: 80Kg
Sash rebate width range (SRW): 395-1310mm
Sash rebate height range (SRH): 500-2350mm
Max SRH:SRW ratio: 1:1.5

If you require a specific part of this system, please find the number on image 2 and follow the corresponding link below:

1. Top Corner Drive: https://store.northwesthardware.co.uk/windows/tilt-and-turn-hardware/Maco-TBT-Corner.html

2. Bottom Corner Drive: https://store.northwesthardware.co.uk/windows/tilt-and-turn-hardware/Maco-Bottom-Corner-Face-Fix.html

3. Pivot Rest: https://store.northwesthardware.co.uk/windows/tilt-and-turn-hardware/Maco-Bottom-Pivot-Rest-Concealed.html

4. Corner Support / Sash Hinge: https://store.northwesthardware.co.uk/windows/tilt-and-turn-hardware/Maco-Corner-Support-Sash-Hinge.html

5. Invisible Scissor Stay Guide & Extension: https://store.northwesthardware.co.uk/windows/tilt-and-turn-hardware/Maco-Invisible-Scissor-Stay-Guide-Extension.html

6. Invisible Scissor Stay Arm: https://store.northwesthardware.co.uk/windows/tilt-and-turn-hardware/Maco-Invisible-Scissor-Stay-Arm.html

7. Horizontal Centre Lock:store.northwesthardware.co.uk/Maco-Horizontal-Centre-Lock.html

8. 15mm BS Variable Handle Height Drive Gear: https://store.northwesthardware.co.uk/maco-drive-gear.html

9. Vertical Centre Lock: https://store.northwesthardware.co.uk/windows/tilt-and-turn-hardware/Maco-Vertical-Centre-Lock-Con.html

10. TBT Striker: https://store.northwesthardware.co.uk/windows/tilt-and-turn-hardware/Maco-TBT-Striker.html
