Atlas Heavy Duty Friction Hinge

Atlas Heavy Duty Friction Hinge

Specifications:

- Distinctive design that offers exceptional strength and performance
- Built with stainless steel construction
- 12″, 14″ and 16″ side hung variants
- 14mm Stack height.
- With 4.8mm counter bore rivet assembly, all metal end caps and a stainless steel reinforcing plate, the Atlas hinge carries a significantly greater weight than a standard hinge.
- All hinges are fabricator-friendly, have a high strength glass reinforced nylon slide and an adjustable brass friction screw
- The asymmetric geometry produces an especially smooth opening and closing action
- Atlas Friction Hinges have additional fixing holes to provide increased stability and easy clean hinges comply with BS8213-1:2004 to provide a 95mm cleaning gap.
- The hinges have been endurance tested in the Nico Test Centre with their maximum load carrying capacity for over 30,000 cycles.
