Avocet Pioneer / Pioneer+ 2 Hook 4 Roller








Avocet Pioneer / Pioneer+ 2 Hook 4 Roller
£51.48
Inc. TAX: £61.78
- SKU: AV2H4R35 / AV2H4RSL35
Available Options
Avocet Pioneer / Pioneer+ 2 Hook 4 Roller
- Trivalent silver finish
- Latch can be changed from the faceplate without removing unit from the profile
- Suitable for lever-lever and lever-pad applications
- Two roller cams for effortless operation
- Can be fitted with shootbolts
- Two opposing hooks, centre deadbolt and shootbolt options for enhanced security
- Reversible centre latch to suit all applications
Pioneer+ Version is BBA Approved to meet PAS23/24 security standards and features a unique sash lifting mechanism which maintains the correct sash to frame alignment to provide trouble free operation.
Technical Details:
Backset: 35mm
Distance between hooks: 1291mm
Distance between rollers: 786mm (inner) / 1437mm (outer)
Faceplate: 16mm
Double Spindle
Overall Length: 2200mm
File | Size | |
---|---|---|
Data Sheet | 800.74KB | Download |
