Overhead Surface Mount Door Closer - White

Overhead Surface Mount Door Closer - White

Power size 2 to 4 adjustable by template
Function: Closing, latching
Cover: no cover
Maximum door width: 1,100 mm
Maximum door weight: 80 kg
Arm application: Fig 1, Fig 6 and Fig 61 fixing positions
Successfully type tested for conformity to all the requirements of BS EN 1154:1997
Included in a successful fire test to BS EN 1634 Part 1. Assessed for use on 30, 60 and 120 minutes timber fire doors.
- Door mount pull (Fig 1), transom mount push (Fig 61): 3|8|4/2|1*|1|3
- Door mount push (Fig 6): 3|8|3|1*|1|3
Certification: CE Marked: 1121-CPD-AD0095; Certifire Approved: CF603; DoP: HUK0025
