Winkhaus activPilot Select Tilt & Turn Full System (Concealed Fix)

Winkhaus activPilot Select Tilt & Turn Full System (Concealed Fix)

- For uPVC elements with a fitting groove of 9 or 13 mm.
- Sash to frame clearance 12 mm (usage range of keeps 9.8 to 14 mm).
- Independent of the overlap (max. 20 mm).
- Opening width up to approx. 95°.
- Can be adjusted without special tools.
- Shear and corner hinge angle with 29 mm installation depth, adapted to practically all standard profile systems.
- Keeps adapted to the frame geometry.

If you require a specific part of this system, please find the number on image 2 and follow the corresponding link below:

3. Top Rod: https://store.northwesthardware.co.uk/windows/tilt-and-turn-hardware/Winkhaus-activPilot-Select-Top-Rod.html
4. Top Shear: https://store.northwesthardware.co.uk/windows/tilt-and-turn-hardware/Winkhaus-activPilot-Select-Top-Shear.html
5. Vertical Interlocking Rods: https://store.northwesthardware.co.uk/windows/tilt-and-turn-hardware/Winkhaus-activPilot-Interlocking-Rods.html
6. Sash Support Bar: https://store.northwesthardware.co.uk/windows/tilt-and-turn-hardware/Winkhaus-activPilot-Sash-Support-Bar-Concealed-Fix.html
7. Bottom Sash & Frame Hinge: https://store.northwesthardware.co.uk/Winkhaus-activPilot-Bottom-Sash-Frame-Hinge-Concealed-Fix.html
8. Horizontal Interlocking Rods: https://store.northwesthardware.co.uk/windows/tilt-and-turn-hardware/Winkhaus-activPilot-Horizontal-Interlocking-Rods.html
